Chapter 5
25 Avaya P120 SMON User Guide
Selecting VLANs to Display
By default, information from all VLANs is displayed in the VLAN Statistics
window. You can limit information being displayed to specific VLANs
using VLAN and TopN filters. For more information, refer to Appendix A,
Using the Define VLAN Filter Dialog Box, and Appendix A, Using the Define
TopN Filter Dialog Box.
VLAN Statistics Variables
The following graphics provide examples of VLAN Statistics windows.
Each figure is followed by a list of variables available in each of the
windows.
Figure 5-1. VLAN Statistics Window - Packets
Table 5-1. VLAN Statistics Variables - Packets
Variable Description
Good Broadcasts/
Multicasts Into Switch The number of good non-unicast packets
entering the switch.
Good Unicasts Into
Switch The number of good unicast packets entering
the switch.
