Chapter 4
21 Avaya P120 SMON User Guide
Port Statistics Variables
The following graphics provide examples of Avaya P120 Port Statistics
windows. Each figure is followed by a list of variables available in each of
the windows.
Figure 4-1. Port Statistics Window - Packets
Table 4-1. Port Statistics Variables - Packets
Variable Description
Collisions The number of collisions occurring on the port or
LAG.
Errors Filtered Out By
Switch The number of error packets filtered out by the
switch.
Good Bcasts/Mcasts
Pkts In The number of good non-unicast packets entering
the switch.
Good Pkts Out The number of good packets leaving the switch.
Good Unicast Pkts In The number of good unicast packets entering the
switch.
