Avaya P120 SMON User Guide 24
5 VLAN Statistics
VLAN Statistics displays detailed statistics for each VLAN. These statistics
can help you maintain proper VLAN configuration. They can also help
you pinpoint problems you may discover using Switch Statistics. For a
detailed overview of VLAN Statistics, refer to “VLAN Statistics Overview”
on page 5.
* Note: The statistics collected for each VLAN only include the
packets that are sent to and from stations connected to the
switch of the device being analyzed. Therefore, any traffic
that does not pass through the switch fabric of the selected
device is not included in the statistics.
Using VLAN Statistics
To access the VLAN Statistics window:
Click .
Or
Select View > VLAN Statistics . The VLAN Statistics application
opens.
To select a set of statistics to display, click one of the radio buttons on the
lower right-hand corner of the window. The statistics sets are:
• Packets - Counters for selected packet types for each VLAN.
• Bandwidth - The rate at which traffic is entering and exiting
each VLAN.
The variables relevant to the selected set of statistics appear under the
graph. Check the variables you want displayed. Statistics for the checked
variables are displayed as bar graphs.
