Chapter 2
9 Avaya P120 SMON User Guide
The Device SMON User Interface
The user interface consists of the following elements:
• Application Tabs - Tabs for switching between the different
views of the Avaya P120 Device.
• Menu Bar - Menus for accessing SMON functions.
• Device SMON Toolbar - Buttons providing shortcuts to
important functions in SMON tools.
• Dialog Area - A resizeable window where all dialog boxes appear.
• Desktop - A resizeable window where SMON windows are
displayed.
• Status Bar - An area at the bottom of each application window
where information about the current application is displayed.
• Status Line - An area at the bottom of the SMON window where
the communication status between Avaya P120 SMON
and the
Avaya P120 Device is displayed.
The figure below shows the user interface, with its various parts labeled.
Figure 2-1. Avaya P120 SMON User Interface
