General Status Indication
A set of indicator LED’s provide the status for Total Accept, Total Reject,
Abnormal, Busy and Power on conditions.
Specifications
The Multi Unit has the following specifications:
20% to 90%
Operation Humidity
0º to 50 ºC (32 º to 122 ºF)
Operation Temperature
NEMA12 Enclosure
Installation requirement
3
(1st, 2nd, and 3rd Rate)
Torque Rate monitoring
areas
16
Fastening Sequences
16
Fastening Parameters
31 per Multi
Maximum number of spindles
Torque Control / Angle Control
Fastening Control Methods
100
Fastening Sequence
Programming Steps
LonWorks
Ethernet 10/100 (Modbus)
ControlNet
CANopen
Modbus Plus
Also Available:
Allen Bradley Remote I/O * (Lic. #199906006)
Mitsubishi CC Link*
Profibus
Interbus-S
DeviceNet
Discrete I/O (24Vdc Sink)
Control Interfaces
RS485 Channel 2 Servo Units Control
RS485 Channel 1 Servo Units Programming
RS232C (Reserved for future use)
RS232C COM2 (Input port)
RS232C COM1 (Data output)
Data Communication
NEC V53A
CPU
Less than 160 ma
In rush current
Less than 70 ma
Operating Current
30 Watt Maximum
Power Consumption
100 to 220 VAC±15%, 1-phase, 50/60 Hz.
Power Supply Voltage
Multi Unit Operation Specifications
* Mitsubishi CC Link & Allen Bradley Remote I/O are proprietary and licensed for use.
