InterBus S Interface Board
InterBus S from Phoenix Contact is a open ring-based, distributed device I/O
network. I/O data is transmitted in frames that provide simultaneous and
predictable updates to all devices in the network. This interface board (S -
version) has up to 512 bytes of assigned input data and 512 bytes of assigned
output data* (64bytes default), two DB9 connectors and status LEDs. The 64
bytes of assigned I/O data allows a maximum of 512 inputs and 512 outputs
per node. FEC I/O is assigned to the I/O points in these data areas (some I/O
will be designated spare). FEC Inputs match the Discrete input layout. FEC
Output location is programmed using the AFC User Console Software.
* When using Master boards where the PCP channel is NOT supported, the
maximum number of I/O will be 20 input bytes/ 20 output bytes.
FEC integrates the Interbus-S board manufactured by HMS Fieldbus Systems
AB into the Multi-Unit modular I/O board. For further technical information
on the Interbus-S interface go to the HMS website. (www.hms.se)
Master/Slave Communication Type
1-256 words Packet Size
Point to point twisted pair Cable
400 m Distance
256 Nodes
500K baud Speed
InterBus Specifications
6002H, 6003H Input objects
6000H, 6001H Output objects
3 LED’s Status Indicator
F3 Hex ID Code
4 words (1 word PCP, 3 word data) Data Width
+5VDC / 200 ma Operating Voltage
Remote bus interface Inters Interface type
512 (Default: 64 output data*) Output data bytes (including free data)
512 (Default: 64 input data*) Input data bytes (including free data)
Interface Specifications
* Actual Input/Output data length is configurable using the AFC Software
package. (See AnyBus-S Reference at the end of this chapter for I/O Setting
example.)
