Data Output Example
The example below shows the format of the COM1 output connected to a
printer. Actual data output format may vary depending on the configuration
and set-up of this port using the AFC User Console Software. The data field
is selectable from all the available output fields to as little as one output field.
(See previous table for available data fields) Headers, Footers & ASCII
control characters are all configurable using the AFC User Console Software.
2002/09/26 09:17:57 SEQ01
SP PA TORQUE ANGLE 1RATE 2RATE OFSET JUG
Acceptable Fastening
01 01 0.50 2 0.000 0.005 0.00 O
2002/09/26 09:19:36 SEQ01
SP PA TORQUE ANGLE 1RATE 2RATE OFSET JUG
Rejected Fastening
01 01 0.17L 0 0.000 0.000 0.00 X
2002/09/26 09:21:16 SEQ01
SP PA TORQUE ANGLE 1RATE 2RATE OFSET JUG
Reset Cycle
01 01 0.23L 0 0.000 0.000 0.00 ! (Before fastening end)
2002/09/26 09:21:21 SEQ01
SP PA TORQUE ANGLE 1RATE 2RATE OFSET JUG
Cycle Stopped
01 01 0.17L 0 0.000 0.000 0.00 ! (Before fastening end)
2002/09/26 09:21:34 SEQ01
SP PA TORQUE ANGLE 1RATE 2RATE OFSET JUG
Abnormal
01 01 0.01 0 0.000 0.000 0.00 A05 (Showing abnormal code)
2002/09/26 09:21:21 SEQ01
SP PA TORQUE ANGLE 1RATE 2RATE OFSET JUG
Spindle Bypassed
01 00 0. 0. 0. 0. 0.
Index
SEQ: Sequence
1RATE: 1st Rate H: High
SP: Spindle 2RATE: 2nd Rate L: Low
PA: Parameter OFSET: Offset Torque
ANGLE: Final Angle JUG: Judgment
