Configurable (ASCII or PLC format

1

)

Data Output format

Configurable (none, even or odd)

Parity

Configurable (1 or 2)

Stop bits

Configurable (7 or 8)

Data bit

Configurable (1200, 2400, 4800, 9600, 19,200)

Speed

RS232C COM1 port specifications (OUTPUT DATA)

Configurable (ASCII format)

Data Input format

Configurable (none, even or odd)

Parity

Configurable (1 or 2)

Stop bits

Configurable (7 or 8)

Data bit

Configurable (1200, 2400, 4800, 9600, 19,200)

Speed

RS232C COM2 port specifications (INPUT DATA)

Reserved for remote data display

RS232C COM3 port specifications

Chapter 2: Setup and Wiring

21

1

PLC format adds STX (beginning of data) and ETX (end of data) control characters
