FEC AFC1500 - Manual (Page 51)

AnyBus - DT Reference (Allen Bradley Remote I/O)
AnyBus DT Initialization
FEC incorporates the ANYBUS module as the interface to various fieldbus
communication devices. (manufactured by HMS, www.hms.se) It is intialized by the
AFC 1500 Multi Unit which sets certain parameters including the size of the Input /
Output tables to be used for the particular fieldbus. The DT model is only used for
the FEC Allen Bradley Remote I/O interface. The AFC User Console software
package is able to configure setup parameters for Allen Bradley Remote I/O as
shown below. (The (DT Type) setup menu is used to input/download this data.)
NOTE: FEC sets this at the Factory, and does not recommend setting this by
the end user. This information is provided for reference only.
DT Address Name Description
3D0h RIO Data Rate 0: 57.6 kbits/sec
1: 115.2 kbits/sec
2: 230.4 kbits/sec
3-255 Not valid (set at 2)
Default value read from Dip Switch
3D1h RIO Rack Address 0x00 - 0x3b valid rack address
0x3c - 0xff invalid setting, set at 0x3b
Default value read from Dip Switch
3D2h RIO Rack Size 0: 1/4 rack
1: 1/2 rack (default)
2: 3/4 rack
3: Full rack
4-255: Not Valid, (set to 3)
3D3h RIO Start Quarter 0: 1st (default)
1: 2nd
2: 3rd
3: 4th
4-255: not valid (set to 3)
Only 0 is valid in block transfer mode
3D4h RIO Last Rack 0: Not last rack (default)
1: Last Rack
2-255: Not valid (set to 1)
3D5h RIO Restart Lockout 0: module reintializes on
communication fault (default)
1: Module locks out, restart with power
down
2-255: Not valid (Set at 1)
3D6h Not used
3D7h RIO IO Mode 0: Mixed mode
1: Mixed mode- IO start at byte 2
2: Only Block transfer
3: Only discrete data (default)
4-255: not valid (set at 3)
