Operation GC-Pro FID
Teledyne Analytical Instruments 52
To monitor the temperatures, check the status of a thermocouple or
change a temperature controller setpoint select “Temperature” from the
MAIN screen. The following screen will display.
4.7.7.1 T HERMOCOUPLE
Selecting “Thermocouple” from the Temperature menu shows the
actual temperature reading (°C) of the three sections: Sample, Sensor,
and Column.
The temperature sensor value will be displayed in degrees
Centigrade. If the values are within the limits the green LED will be
illuminated. The LED will be red if the values are above or below the
