Operation GC-Pro FID
Teledyne Analytical Instruments 42
The phase cycle (forward or reverse) and corresponding phase timer
along with the cell ADC value are displayed in the lower box. The green
LED within the rectangle starts blinking whenever a peak is detected for
active time frames (groups) running in the respective cycle.
The ten groups are split into two screens showing five on each
screen. Either screen can be displayed by selecting “NEXT” and
“PREV” on the HOME screen.
A “Cold Boot” button is located on the bottom left corner of the
HOME screen that when pressed will allow the user to revert back to
factory settings or retain the current instrument settings. See Section
4.7.13.5 for additional details regarding a cold boot.
