GC-Pro FID Appendix
Teledyne Analytical Instruments 97
Appendix
A.1 Specifications and Initial Settings:
Range(s): Refer to Addendum and Testing Results
in Appendix C.
Power Requirements: Refer to Addendum and Testing Results
in Appendix C.
Signal Output:
Ten assignable 4-20 mA DC analog
channels with Channel 0 and Channel 2
having gain and offset capability.
Channel 0 equipped with Wave Function
for ADC count display.
User configurable as: Benzene, other
aromatics, Total HC, etc. and assignable
peak traces.
Alarms:
Two Concentration Alarm ‘C’ Type
relay contacts. User configurable.
One System Alarm for AC power failure
and flame out, fail safe, ‘C’ type relay
contacts.
Calibration Contact: Calibration Contact, ‘A’ Type Relay
contact for span mode indication.
`RS-232 Output: Four selectable RS-232modes
Ambient Temp: 0 – 40º C. Install in a well ventilated
area
