GC-Pro FID Operation
Teledyne Analytical Instruments 43
Each group has buttons associated with it (T_Time and T-Cycle) that
will bring up a graph displaying the analysis trend in the group with
respect to time or cycle. With these buttons, the user can evaluate the
instantaneous analysis as opposed to waiting for a complete cycle to
terminate. See Section 4.7.13 for more details.
4.7.3 The MENU Screen
Instrument parameters can be accessed and set by pressing the
“MENU” button on the HOME screen. This brings up the following
MENU screen:
Any function can be entered by touching the respective icon. The
functions are:
 Standby (lower left corner on display)
 Home (home icon at bottom center)
 Overlay Chromatogram
 Timing
 Temperature
 Group Setup
 Analog Adjust
 Calibration
 Self Test
