26
3-10 Setup Procedure For The Batcher (continued)
From the previous page, we are in the POINT setting portion of the 16 Point setup
Menu.
PRESS DISPLAY
then
POINT 01
F 1
The unit displays the last frequency entered for Point 01.
F 0
Clears out existing frequency for Point 01.
F 100
Sample frequency, or enter desired value from worksheets.
K 1
The unit displays the last K Factor entered for Point 01.
K 0
Clears out existing K Factor for Point 01.
K 10
Sample K Factor, or enter desired value from worksheets.
POINT 02
The above procedure is now repeated for Point 02. The setup continues in this manner
until up to 16 points are entered.
Note: A minimum of (3) three points must be entered. All frequencies of consecutive point
numbers must be entered in ascending order, beginning with 0 for the first point.
Please read Section 7-3 for all rules concerning 16 Point Frequency and K Factor entry.
PRESS
DISPLAY
POINT 00
Clears Point number in preparation for exit of 16 Point setup routine.
Last count, unit now in Run Mode.
Press ENT on Point 00 to exit 16 Point routine.
Note: Unit will flash BAD FREQ if there is a sequence error. The unit will then display the
sequence error point number so that corrections can be made.
16 Point linearization is now setup.
1
ENT
ENT
CLR
1 0 0
ENT
CLR
1 0
ENT
CLR
ENT
