17
3-10 Setup Procedure For The Batcher (continued)
MENU ITEM 5 RATE
Setting the Ratemeter
PRESS DISPLAY
PRESET
↓↓↓↓↓
PREWARN
↓↓↓↓↓
PRE TYP
↓↓↓↓↓
COUNT
↓↓↓↓↓
RATE
↓↓↓↓↓
K FACTOR
This selects the Ratemeter portion of the menu.
K FACTOR flashes then shows the current Ratemeter K Factor.
Note: The K Factor setup is skipped if the unit has 16 Point option. The unit goes
directly to WINDOW.
0 Flashes.
Clears out existing K FACTOR.
12.056 Flashes.
Sample K Factor, or enter calculated value from notes or worksheet.
WINDOW ##
Store new K Factor.
Normally the ratemeter updates each second. If no signal comes in during that time, the
ratemeter will wait until the window times out or a signal comes in; the display will not update.
The window is the maximum sample time, in seconds, on which the waiting period is based.
The range is from 02 to 24 seconds.
WINDOW 00
Clears out existing WINDOW number value.
WINDOW 05
As an example, extends the window to 5 seconds.
continued on next page
D
D
D
ENT
D
CLR
D
1 2 D 0 5 6
ENT
5
CLR
