Liquid Controls SP2800 User Manual

Page 23

3-10 Setup Procedure For The Batcher (continued)

MENU ITEM 6 LOCKOUT

This menu item uses a 4 digit security code to prevent unwanted changes in the programming
or improper use of the Batcher. The unit is shipped from the factory with a security setting of
00 and a lockout code of 1000.

Security example: First set the security shut down time in the Lockout menu then go to the
Run Mode. Press the START button. The word STARTED should briefly appear. If no signal
comes in before the security time is reached, the unit locks and displays SECURITY. Once
the unit locks all buttons except 0 thru 9 are disabled. To unlock the unit simply press in the
lockout code. When the unit is unlocked all menu features are available for change.

Lockout example: To lock the unit, first make sure it is in the Run Mode, then press 1 - 0 - 0 -
0. The words LOCK ON should briefly appear. Once the unit is locked:

a. Preset can still be accessed and changed.
b. Prewarn can still be accessed but cannot be changed.
c. the rest of the menu cannot be accessed.

To unlock the unit simply press 1 - 0 - 0 - 0. The words LOCK OFF will appear briefly. When
the unit is unlocked all menu features are available for change.

To put in a different security time or lockout code follow this setup procedure.

PRESS

DISPLAY

PRESET

↓↓↓↓↓

PREWARN

↓↓↓↓↓

DEV TYP

↓↓↓↓↓

LOCKOUT

↓↓↓↓↓

SECUR ##

SECUR is the time, in seconds, that the unit will wait between pulses or for a
signal to come in once STARTED. For example: The SECUR is set at 15, in run
mode the START button is pressed. If at any time the unit does not receive a signal for
15 seconds the display will go to security and the unit will lock itself. The unit retains
elapsed security time if STOPPED before security times out. When restarted, the unit
resumes security timing from where it left off. As soon as a signal comes in the security
time is reset. Entering a security time of 00 disables the security feature.

SECUR 00

Clears out existing security time.

SECUR 34

As an example, unit waits 34 seconds before Security Mode.

Continued on next page

ENT

CLR
