Liquid Controls SP2800 User Manual

Page 28

3-10 Setup Procedure For The Batcher (continued)

From the previous page, we are in the SET HIGH setting portion of the ALG OUT setup Menu.

PRESS

DISPLAY

0 Flashes.

Clears out existing High Setpoint value.

6759.5 Flashes.

Sample High Setpoint, or enter value from notes or worksheet. (D for decimal point.) If
High Setpoint is too low, the warning HIGH

≤

LOW will be displayed and the unit will

return to the SET LOW routine.

Last count, unit now in Run Mode.

High Setpoint is stored.

Analog Output is set.

MENU ITEM 9 OUT FREQ

All models of the Batcher have a pulse generator built in to them. This Output Frequency
generator sends pulses out which are scaled relative to the input signal via the counter K
Factor. This means that for every time the counter increments a pulse is available at the output.
Various output frequencies are available to the user for driving external devices. In case the rate
exceeds the output frequency selected, a 9999 pulse buffer is provided to hold the excess pulses.
If the buffer is completely filled the warning message DATALOST will flash on the display.

PRESS

DISPLAY

PRESET

↓↓↓↓↓

PREWARN

↓↓↓↓↓

Press until . . .

OUT FREQ

↓↓↓↓↓

20000

↓↓↓↓↓

Enters the routine for setting up the Frequency Output.
The display shows the last Frequency selection.

2000

↓↓↓↓↓

200

↓↓↓↓↓

Press D to go to 20000

↓↓↓↓↓

Press ENT at desired Frequency.

Last count unit now in Run Mode.

Pulse Output is now set.

CLR

ENT

9 D 5

ENT
