Asus Pedestal/5U Rackmount Server TS500-E4 Server - Manual (Page 35)

2-13 ASUS TS500-E4
Before you can install a 5.25-inch drive, you should first remove the
front panel assembly (front bezel and front panel cover). The front panel
assembly is attached to the chassis through three hooked tabs on the
left side and four hinge-like tabs on the right side.
To remove the front panel assembly:
1. Locate the four hooked tabs on the
chassis side rail.
2. Press each lock tab to release the front
panel from the chassis.
2.5 Front panel assembly
2.5.1 Removing the front panel assembly
3. Pull and swing the left edge of the front
panel outward.
