Key Release

Emergency Vehicle Access Conditions

Fail-Secure Manual Release System (Owner Installed)

Solenoid lock does NOT allow the clutch plate to rotate when:

The AC power is on but the operator is not cycling.

The AC power is turned off.

AC power failure.

1. During normal AC powered operation, emergency vehicles access the gate by a separate emergency access
device individually installed and wired to your gate system. The type of devices that can be used in your commu-
nity depends on your city codes. These devices may include (but are not limited to) Fire Department lock boxes,
Click-2-Enter radio receivers, strobe light sensors, siren sensors, etc.

2. In the event of an AC power failure, the emergency vehicle access device will not function because the gate
operator is un-powered. “Fail-Safe” or “Fail-Secure” release systems for the 9100 allow the gate to be manually
operated during AC power failure. ONLY the “Fail-Safe” release system allows the gate to be manually operated
without unlocking the operator first and has been designed that way to allow emergency personnel to immediately
manually operate the gate from either side under emergency situations.

This automatic vehicular gate system is designed to allow access to emergency vehicles under different operating conditions.

Solenoid

Lock

Clutch Plate

Clutch Plate

Operator
Housing

Solenoid lock automatically retracts and allows clutch
plate to rotate ONLY during normal gate cycling.

Turning key 1/2 turn
retracts solenoid lock
and allows clutch plate
to rotate for manual
operation with or
without AC power.

W

ARNING

MO

VI

NG

GAT

E C

AN

CAUSE

Op

era

te ga

te o

nly

w

he

n ga

te a

rea

is i

n s

ight

and

free

of

pe

opl

e a

nd

obs

truc

tion

s.


Do

not

allow

chi

ldr

en

to pl

ay i

n ga

te a

rea

or

op

era

te ga

te.


Do

not

sta

nd

in

ga

te pa

th or

w

alk

thr

ough

pa

th

whi

le ga

te is

m

oving.


Re

ad o

wne

r’s m

anua

l and

safe

ty ins

truc

tions

.

SER

IOU

S IN

JU

RY

OR

DE

ATH

CL

ASS

CE

RT

IFIED

TO

CAN/

CSA

C2

2.2

NO.

247

CONFORM

S

TO

ANSI

/UL-

325

VE

HIC

UL

AR

GAT

E O

PER

AT

OR

HP

533

82

MODE

L

SE

RI

AL

VO

LTS

PH

ASE

AM

PS

60

Hz

MAX

GA

TE LOAD

Door

King, In

c., Inglew

ood,

CA

ON

12

3

4

5
6 7 8

SW 2

This manual release system (Installed 2600-862 Fail-Secure Manual Release Kit) allows the gate to be manually
operated ONLY after unlocking the gate operator.
Power outages or turning power off WILL NOT allow gate to be
manually operated without physically unlocking the gate operator with the key first. This option is typically used in Class
III and Class IV applications.
The gate operator “Fails” (Loss of AC power) in a “Secure” (Manually in-operable) condition.

SW 2, switch 4 must be ON.

Important:

solenoid lock

MUST be in position shown.
