SECTION 6 - OPERATING INSTRUCTIONS

WARNING

- To reduce the risk of injury or death:


1. READ AND FOLLOW ALL INSTRUCTIONS.

2. Never let children operate or play with gate controls. Keep the remote control away from children.

3. Always keep people and objects away from gate.

NO ONE SHOULD CROSS THE PATH OF THE MOVING GATE

.

4. Test the operator monthly. The gate MUST reverse on contact with a rigid object or stop or reverse when an object

activates the non-contact sensors. After adjusting the force or the limit of travel, retest the gate operator. Failure to

adjust and retest the gate operator properly can increase the risk of injury or death.

5. Use the emergency release only when the gate is not moving and power has been shut-off.

6. KEEP GATES PROPERLY MAINTAINED. Read the owner's manual. Have a qualified service person make repairs to gate

hardware.

7. The entrance is for vehicles only. Pedestrians must use separate entrance.

8.

SAVE THESE INSTRUCTIONS

.

Unlock the power switch cover and open to access the Main Power, and the
operator Reset switch.

AC

POWER

OFF

RESET

6.1 AC Power and Reset Switch

Reset Button

- Used to turn off

the entrapment alarm and to
reset the operator after a HARD
shutdown has occurred.

Alarm Siren

AC Power Switch

- Powers the

operator ON (toggle up) or
OFF (toggle down).

IMPORTANT SAFETY INSTRUCTIONS

Every time the 9100 is powered up, the First open command will automatically run “Multiple
gate cycles”
that will locate and remember the gate’s open and close positions (See page 24).
