9100-065-Z-3-13

28

ON

EXIT
LOOP

4602

SW1

NC

NO

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

ON

EXIT
LOOP

4602

SW1

NC

NO

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

Wireless Reverse Edge Sample Setup - Single Receiver

Photo Sensor and Wireless Reverse Edge Sample Setup

Closed Gate

Wall

Normally Open

Common

Normally Open

Install Jumper Wire

Normally Open

Normally Open

Common

Filler Post Note: Install reversing edges on all
the gate support posts or filler post in this area
(e.g. cantilever gate installations, See below).

Wireless Note: Refer to the
instruction sheet that comes
with the receiver/transmitter
for more specific wiring and
mounting instructions.

Closing-
Direction
Reversing
Edge

Closing-
Direction
Reversing
Edge

Opening-Direction Reversing Edge

5-Pin UL 325 Terminal Wiring

Opening-Direction Reversing Edge (If filler post is used).

9 V battery operated transmitter mounted on gate.

Filler Post
(If necessary)

Edge

Transmitter

Coax Antenna Kit
P/N 1514-073

Com

Com

Antenna mounted
outside operator cover.

24 VAC Receiver

Place receiver in operator.

5-Pin UL 325 Terminal Wiring

Normally Open

Normally Open

Common

Com

Opening-Direction Photo Beam

Normally Open

Common

Wireless Note: Refer to the
instruction sheet that comes
with the receiver/transmitter
for more specific wiring and
mounting instructions.

24 Volt

24 Volt

24 VAC Receiver

Place receiver in operator.

Photo Sensor Power Note:
Photo sensors can be powered
by the built-in convenience
outlets located on the operator
(See page 24).

Install Opening-Direction

reverse edges on the gate

support post(s) in this area.

Cantilever Gate

Coax Antenna
Kit
P/N 1514-073

Antenna mounted
outside operator
cover.

OPEN Entrapment Sensor

CLOSE Entrapment Sensor

OPEN Contact Sensor

CLOSE Contact Sensor

Low Voltage Common

OPEN Entrapment Sensor

CLOSE Entrapment Sensor

OPEN Contact Sensor

CLOSE Contact Sensor

Low Voltage Common

Power is
limited to
250 mamps.

Power is limited
to 250 mamps.

Main

Terminal

Main

Terminal

Edge

Transmitter

9 V battery operated
transmitter mounted on gate.

1
2

3
4
5

1

2

3
4
5

When either direction reversing
edge gets obstructed, the gate will
STOP and reverse direction.

When a reversing edge gets obstructed, the
gate will STOP and reverse direction. When
a photo beam gets obstructed the gate will
STOP, then continue in the same direction
after obstructed photo beam has been
cleared until the gate cycle is complete.
