Manually Configuring Port-Forwarding
41-001134-05, Rev 00, Rel. 1.1 C-11
Remote Office Installation and Configuration of the Phone (Phone -Side)
The following table is the port mapping table after a successful UPnP session with
the phone-side Home Router.
Home Router Port Mapping Table
8 Enter the HTTP port start (for example, 51510).
The Phone prompts for a NAT IP address.
9 Enter the Home Router WAN-side IP address.
The phone prompts for the SIP port.
10 Enter the SIP port for the Home Router. For example, you can enter 51620.
The Phone prompts for an RTP port.
11 Enter the RTP port for the Home Router. For example, you can enter 51720.
The Phone prompts for an HTTPS port.
Action Name Source Destination Protocol
Allow WAN, * LAN, 192.168.1.3 UDP, 5060-51620
Allow WAN, * LAN, 192.168.1.3 TCP, 80-51510
Allow WAN, * LAN, 192.168.1.3 UDP, 3000-51720
Allow WAN, * LAN, 192.168.1.3 UDP, 3001-51721
Allow WAN, * LAN, 192.168.1.3 UDP, 3002-51722
Allow WAN, * LAN, 192.168.1.3 UDP, 3003-51723
AastraLink Pro 160 Remote Office Configuration
Step Action
