Manually Configuring Port-Forwarding
C-10 41-001134-05, Rev 00, Rel. 1.1
AastraLink Pro 160 IP Phone User Guide
Remote Phone Installation and Port-Forwarding Configuration
Example
The following is an example of installing and setting up up your remote phone for
port-forwarding.
AastraLink Pro 160 Remote Office Configuration
Step Action
Configure Port Forwarding
1 Manually setup the required port forwarding on the Home Router.
Note: Refer to the “Home Router Port Mapping Table” on page C-11 .
Install the Remote IP Phone (Pre-Stage Phone)
2 Press when remote phone is in the Auto-Discovery screen.
If the phone cannot find a UPnP enabled device, it displays “UPnP device not found”. Press .
The phone prompts for the NAT IP address.
3 Enter the Home Router WAN-side IP address. For example: 65.96.171.130
The phone prompts for the SIP port.
4 Enter the SIP port for the Home Router. For example, you can enter 51620.
The Phone prompts for an RTP port.
5 Enter the RTP port for the Home Router. For example, you can enter 51720.
The Phone prompts for an HTTPS port.
6 Enter the HTTPS port for Home Router. For example, you can enter 51510.
Install the Remote IP Phone (Non-pre-Stage Phone)
7 Press and enter the server external gateway IP address (for example, 65.215.35.80).
The Phone prompts for an HTTP port.
