Step 5 - attach plow system to the forward mount – Kolpin 10-0520 X-Factor Plow User Manual
Page 19
19
© 2011 Kolpin Outdoors Inc.
STEP 5 - ATTACH PLOW SYSTEM TO
THE FORWARD MOUNT:
1. Refer to Operating Instructions, Page 3.
2. Once the plow system is attached to your ATV and
the plow blade is on the ground, adjust the blade
stops and blade spring tension as desired to achieve
best performance. Refer to Illustrations 13 and 14.
3. Once the desired blade position is obtained, torque
the blade stop fasteners to specification.
FASTENER TORQUE:
17ft. lbs. (23 Nm)
