2.2 Description of the konti-Dos mobile system
The konti-Dos mobile system is a konti-Dos wall system fitted to a mobile unit. It has, in addi-
tion, a storage reservoir with a mixer and a suction hose, an IP44 multi-socket fixed to the rear
of the system for the control unit, dosing pump, mixer and optional circulation pump electrical
connections.
All the components are installed on a stainless steel trolley with pneumatic wheels.
The mobile system includes a pressure regulator to adjust the inlet pressure to an authorised
value (acceptable pressures: please consult the standard versions table).
Dimensions W x H x D approx. 476 x 1203 x 674 mm
Water connections G 1/2“ (all)
Mixer electrical consumption 25 W
Dosing pump and control unit
electrical consumption
< 30 W
Stainless steel
trolley with wheels
Mixer with gear
reducer (65 rpm)
Multi-socket base
for the electrical
supply (IP44 protection)
Konti-Dos type
8025 control unit
Water flow sensor
Reservoir for the active
product, in polyethylene,
capacity 40 l
Screw-on cover with
opening, Ø 160 mm
Dosing pump (PVDF
version, maximum 48 l/h)
