S

ensor

A

ktor

M

odul

Description of initiation files EDS

Description_of_InitiationFilesEDS_2

Version 1.4

page 1 / 27

HISTORY

Document

version

EDS

version

Firmware

version

date

changes

1.4

1.11

A.01.00.00

2014-04-09

- eds has to be reworked to used Object range 0x2F00 instead of 0x3800 to

be conform with requirements.

1.3

1.10

A.00.09.00

2014-03-24

- Totalizer and Totalizer_Customer moved to 0x38FE and 0x38FF
- New Objects 0x2D03sub19 (0x2D04) Autotune Zero Value
- New object 0x200A Power Supply Alarm Values

1.2

1.8

A.00.08.05

2014-02-28

- Device Status Object (0x2004) reworked. Sub Indices reworked
- Device Status object includes sub index 1 with devices Namur state which

is mapped cyclic.

1.1

1.7

A.00.07.03

2013-12-09

- Device Status Object (0x2004) added
- Diagnose Object (0x2D01) some objects removed

1.0

1.6

A.00.07.00

2013-11-20

1

st

version

Contents

history ............................................................................................................................ 1

Additional information ................................................................................................... 3

Accesstype ............................................................................................................................................................................ 3

Flags ......... ............................................................................................................................................................................ 3

Accesrights ............................................................................................................................................................................ 3

objects ........................................................................................................................... 4

0x2000

.....

Buerkert Device Description Object ................................................................................................................... 4

0x2001

.....

Device Communication Object .......................................................................................................................... 4

0x2002

.....

User Configuration Object ................................................................................................................................. 5

0x2003

.....

Error Management Object ................................................................................................................................. 5

0x2004

.....

Device Status Object .......................................................................................................................................... 6

0x2005

.....

Modul Status Object .......................................................................................................................................... 7

0x200A

....

Power Supply Alarm Values ............................................................................................................................... 8

0x2010

.....

Physical Group ................................................................................................................................................... 9

0x2011

.....

Loical Group ....................................................................................................................................................... 9

0x2100

.....

Get Mapping Function ....................................................................................................................................... 9

0x2101

.....

Locating Function ............................................................................................................................................... 9

0x2102

.....

Blockdownload Config Function ...................................................................................................................... 10

0x2103

.....

Persistent Storage Function ............................................................................................................................. 10

0x2220

.....

EDS ................................................................................................................................................................... 10

0x2400

.....

Sensor Type ...................................................................................................................................................... 10

0x2420

.....

No Measure Values .......................................................................................................................................... 10

0x2421

.....

No Control Values ............................................................................................................................................ 11

0x2422

.....

No Calibration Values ....................................................................................................................................... 11

0x2500

....

Current SP Nl_min ............................................................................................................................................. 11

0x2501

.....

Actual Flow Nl_min .......................................................................................................................................... 12
