Description of initiation files EDS
Description_of_InitiationFilesEDS_2 Version 1.4 page 12 / 27
0x2501 Actual Flow Nl_min
Cyclic actual flow as REAL32. It’s mapped by TPDO 0 (0x1A00sub1).
Object can be used for automatically bueS configuration in a bueS system.
sub name description
ac
ce
ss
type
flags accessrights
im
p
o
rt
Im
p
o
rt
d
e
vID
S
IM
-C
a
rd
R
-
u
se
r
W
-
u
se
r
R
-
a
d
v.
u
s
e
r
W
-
a
d
v.
u
se
r
R
-
in
sta
ll
e
r
W
-
ins
ta
lle
r
R
-
b
u
e
rke
rt
W
-
b
u
e
rke
rt
1 x « 0 » actual flow RWR x - x - x - x -
2 Unit
« 0xA04700 » bueS specific SI unit : Nl/min
Other units are handled by display
or Buerkert Communicator
RO x - x - x - x -
3 Name « Actual Flow » objects name RO x - x - x - x -
4 Classification « 0x0003 » bueS specific RO x - x - x - x -
5 Datatype « 0x08 » REAL32 RO x - x - x - x -
6 Precision bueS specific RO x - x - x - x -
7 Feature Group
« 0 » bueS specific
Is used for automatic configuration
of bueS systems
RW x x x x x x x x x
0x2502 Current Dutycycle
Cyclic current valves duty cycle as REAL32. It’s mapped by TPDO 1 (0x1A01sub2).
Object can be used for automatically bueS configuration in a bueS system.
sub name description
ac
ce
ss
type
flags accessrights
im
p
o
rt
Im
p
o
rt
d
e
vID
S
IM
-C
a
rd
R
-
u
se
r
W
-
u
se
r
R
-
a
d
v.
u
s
e
r
W
-
a
d
v.
u
se
r
R
-
in
sta
ll
e
r
W
-
ins
ta
lle
r
R
-
b
u
e
rke
rt
W
-
b
u
e
rke
rt
1 y2
« 0 » valves dutycycle (actuating
variable)
RWR x - x - x - x -
2 Unit
« 0xFE000000 » bueS specific : value as %
Other units are handled by display
or Buerkert Communicator
RO x - x - x - x -
3 Name « Current Dutycycle » objects name RO x - x - x - x -
4 Classification « 0x000E » bueS specific RO x - x - x - x -
5 Datatype « 0x08 » REAL32 RO x - x - x - x -
6 Precision bueS specific RO x - x - x - x -
7 Feature Group
« 0 » bueS specific
Is used for automatic configuration
of bueS systems
RW x x x x x x x x x
