Description of initiation files EDS
Description_of_InitiationFilesEDS_2 Version 1.4 page 14 / 27
0x2540 SP Nl_min
Cyclic setpoint as REAL32. It’s mapped by RPDO 0 (0x1600sub1).
Object can be used for automatically bueS configuration in a bueS system.
sub name description
ac
ce
ss
type
flags accessrights
im
p
o
rt
Im
p
o
rt
d
e
vID
S
IM
-C
a
rd
R
-
u
se
r
W
-
u
se
r
R
-
a
d
v.
u
s
e
r
W
-
a
d
v.
u
se
r
R
-
in
sta
ll
e
r
W
-
ins
ta
lle
r
R
-
b
u
e
rke
rt
W
-
b
u
e
rke
rt
1 w
« 0 » controllers setpoint
(is used if it’s selected by setpoint
source of Controller Object
0x3811sub3)
RWW x x x x x x x x
2 Unit
« 0xA04700 » bueS specific SI unit : Nl/min
Other units are handled by display or
Buerkert Communicator
RO x - x - x - x -
3 Name « Setpoint » objects name RO x - x - x - x -
4 Classification « 0x0003 » bueS specific RO x - x - x - x -
5 Datatype « 0x08 » REAL32 RO x - x - x - x -
6 Precision bueS specific RO x - x - x - x -
7 Feature Group
« 0 » bueS specific
Is used for automatic configuration
of bueS systems
RW x x x x x x x x x
8 Res lower Limit « 0 » RO x - x - x - x -
9 Res upper Limit
value depends on QNom of actual
calibration curve
RO x - x - x - x -
0x2541 Manual SP Nl_min
It’s used for bueS mode.
Cyclic manual setpoint as REAL32, it’s used by display to change the setpoint manually.
Object can be used for automatically bueS configuration in a bueS system.
sub name description
ac
ce
ss
type
flags accessrights
im
p
o
rt
Im
p
o
rt
d
e
vID
S
IM
-C
a
rd
R
-
u
se
r
W
-
u
se
r
R
-
a
d
v.
u
s
e
r
W
-
a
d
v.
u
se
r
R
-
in
sta
ll
e
r
W
-
ins
ta
lle
r
R
-
b
u
e
rke
rt
W
-
b
u
e
rke
rt
1 manual_w
« 0 » controllers setpoint
It’s used in bueS mode for manual setpoint
manipulation by e.g. display
(is used if it’s selected by setpoint source of
Controller Object 0x3811sub3)
RWW x x x x x x x x
2 Unit
« 0xA04700 » bueS specific SI unit : Nl/min
Other units are handled by display
or Buerkert Communicator
RO x - x - x - x -
3 Name « Manual Setpoint » objects name RO x - x - x - x -
4 Classification « 0x0003 » bueS specific RO x - x - x - x -
5 Datatype « 0x08 » REAL32 RO x - x - x - x -
6 Precision bueS specific RO x - x - x - x -
7 Feature Group
« 0 » bueS specific
Is used for automatic configuration
of bueS systems
RW x x x x x x x x X
8 Res lower Limit « 0 » RO x - x - x - x -
9 Res upper Limit
value depends on QNom of actual
calibration curve
RO x - x - x - x -
