Description of initiation files EDS
Description_of_InitiationFilesEDS_2 Version 1.4 page 16 / 27
0x2C00 Actual Flow
Cyclic actual flow as REAL32. It’s mapped by TPDO 2 (0x1A02sub1).
It’s used for CANopen mode. The actual flow is transmitted in the choosen unit (sub2).
Object can be used for automatically bueS configuration in a bueS system.
sub name description
ac
ce
ss
type
flags accessrights
im
p
o
rt
Im
p
o
rt
d
e
vID
S
IM
-C
a
rd
R
-
u
se
r
W
-
u
se
r
R
-
a
d
v.
u
s
e
r
W
-
a
d
v.
u
se
r
R
-
in
sta
ll
e
r
W
-
ins
ta
lle
r
R
-
b
u
e
rke
rt
W
-
b
u
e
rke
rt
1 Actual Flow_x Actual flow in choosen unit (sub2) RWR x - x - x - x -
2 Unit
Describe the objects used unit.
Unit is stored for every calibration curve (see Sensor _x
Object 0x2D03.. 0x2D0C subF). This unit is equal to the
selected gas.
Details of unit values see attachement.
RW x x x x x x x x
3 Flow Full Scale devices nominal flow of selected gas RO x - x - x - x -
4 Sens Raw Flow Sensor raw flow value RWR - - x - x - x -
5 Sens Raw Temp Sensor raw temperature value RWR - - - - x - x -
0x2C10 Prop Valve
sub name description
ac
ce
ss
type
flags accessrights
im
p
o
rt
Im
p
o
rt
d
e
vID
S
IM
-C
a
rd
R
-
u
se
r
W
-
u
se
r
R
-
a
d
v.
u
s
e
r
W
-
a
d
v.
u
se
r
R
-
in
sta
ll
e
r
W
-
ins
ta
lle
r
R
-
b
u
e
rke
rt
W
-
b
u
e
rke
rt
1 Frequency Min used minimal frequency for valves dutycycle RO x - x - x - x x
2 Frequency Max used maximal frequency for valves dutycycle RO x - x - x - x x
3 Frequency Shift
« 0 » it’s possible to shift the frequency in range of +/-
10.0%
It’s used by customer to manipulate the valves
frequency
RW x - x x x x x x
4 Valve Type Assambled valve type RW x - x - x x x x
5 Valve Coil Coil of assambled valve RW x - x - x x x x
6 Valve Orifice Orifice of assambled valve RW x - x - x x x x
7 Leak Tight Pres Leak tight pressure of assembled valve as bar rel. RO - - x - x - x x
8 Actuator Override
Describe the valves behavior.
« 0 » EnActuatorOverride_Automatic
(use dutycycle input object 2541sub1)
1 EnActuatorOverride_CloseValve
2 EnActuatorOverride_OpenValve
3 EnActuatorOverride_Hold (freeze last value)
RW x x x x x x x x
