Description of initiation files EDS
Description_of_InitiationFilesEDS_2 Version 1.4 page 11 / 27
0x2421 No Control Values
no objects
0x2422 No Calibration Values
no objects
0x2500 Current SP Nl_min
Cyclic current used setpoint as REAL32 for closed loop control. It represents the used setpoint which is manipulated e.g.
rise time. For more information see 0x2F11
Controller Object.
It’s mapped by TPDO 1 (0x1A01sub1).
Object can be used for automatically bueS configuration in a bueS system.
