0x2503
Medium Temperature
Cyclic medium temperature as REAL32. It’s mapped by TPDO 0 (0x1A00sub2).
Object can be used for automatically bueS configuration in a bueS system.
sub name
description
ac
ce
ss
type
flags
accessrights
im
p
o
rt
Im
p
o
rt
d
e
vID
S
IM
-C
a
rd
R
-
u
se
r
W
-
u
se
r
R
-
a
d
v.
u
s
e
r
W
-
a
d
v.
u
se
r
R
-
in
sta
ll
e
r
W
-
ins
ta
lle
r
R
-
b
u
e
rke
rt
W
-
b
u
e
rke
rt
1 Medium Temp
« 0 »
temperature of the medium
0..3276 Kelvin is scaled to 0 -
65535
Resolution is 0.05 Kelvin
RWR
x - x - x - x -
2 Unit
« 0x050000»
bueS specific SI unit : Kelvin
Other units are handled by display
or
Buerkert Communicator
RO
x - x - x - x -
3 Name
« Medium Temp.»
objects name
RO
x - x - x - x -
4 Classification
« 0x0001»
bueS specific
RO
x - x - x - x -
5 Datatype
« 0x06 »
UINT16
RO
x - x - x - x -
6 Precision
bueS specific
RO
x - x - x - x -
7 Feature Group
« 0 »
bueS specific
Is used for automatic configuration
of bueS systems
RW
x
x x x x x x x x
0x2504
Current Totalizer Nl
Cyclic current totalizer as REAL32. It’s mapped by TPDO 2 (0x1A02sub2).
Object can be used for automatically bueS configuration in a bueS system.
