Description of initiation files EDS
Description_of_InitiationFilesEDS_2 Version 1.4 page 19 / 27
0x2D03 Sensor _1
0x2D04 Sensor _2
Detailed information see attachment: General Description of flow sensor.
sub name description
ac
ce
ss
type
flags accessrights
im
p
o
rt
Im
p
o
rt
d
e
vID
S
IM
-C
a
rd
R
-
u
se
r
W
-
u
se
r
R
-
a
d
v.
u
s
e
r
W
-
a
d
v.
u
se
r
R
-
in
sta
ll
e
r
W
-
ins
ta
lle
r
R
-
b
u
e
rke
rt
W
-
b
u
e
rke
rt
1 Curve Calibrated
Defines if the curve is calibrated by manufacturer.
If it isn’t, a customer specified calibration is impossible.
0: curve isn’t calibrated
1: curve is calibrated
RW x - x - x - x x
2 Used Cal Points
Defines the amount of used calibration points from the
manufacturers calibration curve.
RO - - - - x - x x
3 Calibration Medium Name of the medium used for calibration by manufacturer RO x - x - x - x x
4 Medium Name of medium for which the device is calibrated RO x - x - x - x x
5 Medium Density Density of medium for which the device is calibrated RO x - x - x - x x
6 Temp Komp A
Temperature compensation factor A for the medium for
which the device is calibrated
RO - - - - x - x x
7 Temp Komp B
Temperature compensation factor B for the medium for
which the device is calibrated
RO - - - - x - x x
8 Cal Temperature
Temperature while device was calibrated in degree celcius
as float32 value.
RO - - x - x - x x
9 Cal Pres Pressure for which the device is calibrated (inlet pressure) RO x - x - x - x x
A Assembly Pos
Position at which the device was calibrated.
Details see attachment “
Assembly position ”
RO x - x - x - x x
B QNom Min [Nl/min] Minimum value for QNom RO - - x - x - x x
C QNom Max [Nl/min] Maximum value for QNom RO - - x - x - x x
D QNom [Nl/min]
Devices nominal flow rate in Nl/min
Possible range is defined by QNom Min and QNom Max
RW x x x - x x x x x x
E Span
Defines the sensors span in percent as REAL32 (0.1% –
20%).
e.g. a span of 1:50 is represented by a value of 2 %
it defines the minimum value for which the calibration is
usable
RO - - x - x - x x
F Used Unit
Describes the used unit.
By default the used unit is equal for which the device is
ordered.
The unit can be changed by customer.
See attachment: flow units
RW x x - - x x x x x x
10 Cal Date Manufacturers date of calibration RO - - x - x - x x
11 Cal Site Manufacturers site of calibration as number RO - - x - x - x x
12 Calibrator Manufacturers calibrator as number RO - - - - x - x x
13 Cal Number Manufacturers calibration number RO - - x - x - x x
14
Medium Name
Customer
Name of medium which is used by customer
If not other specified the value is set by testbench same like
the Calibration Medium (sub3).
RW x x - x x x x x x
15
Userdefined Curve
Active
Defines if customers calibration curve is active.
0: manufacturer calibration curve active
1: user defined calibration curve active
RW - - x x x x x x
16
Userdefined Used Cal
Points Defines the amount of used calibration points from the user
defined calibration curve.
RW - - x x x x x x
17
Userdefined Cal
Temperature Temperature while device was calibrated by user in degree
celcius as float32 value.
RW - - x x x x x x
18 Userdefined Cal Date Date of users calibration RW - - x x x x x x
19 Autotune Zero Value Sensor raw value during last autotune RW - - - - - - x x
