Description of initiation files EDS
Description_of_InitiationFilesEDS_2 Version 1.4 page 27 / 27
0. EnFactorySetting_SFS7011_heater_low_power
1. EnFactorySetting_SFS7011_heater_medium_power
2. EnFactorySetting_SFS7011_heater_normal_power
3. EnFactorySetting_SFS7011_heater_maximum_power
STORAGE GROUPS
#define GROUP_ALL 255
#define GROUP_SHUTDOWN 0
#define GROUP_DIRECTLY 1
#define GROUP_SYSPARAM_1 10
#define GROUP_SYSPARAM_2 11
.. ..
#define GROUP_SYSPARAM_10 19
#define GROUP_CALCURVE_1
20
#define GROUP_CALCURVE_2 21
.. ..
#define GROUP_CALCURVE_10 29
#define GROUP_CALCURVE_CUSTOM_1
30
#define GROUP_CALCURVE_CUSTOM_2 31
.. ..
#define GROUP_CALCURVE_CUSTOM_10 39
storage location (for Access Control 4 only)
LOCATION_ALL 255
LOCATION_INTERALFLASH 1
LOCATION_EEPROM_1 2
LOCATION_SIMCARD 3
BAUDRATES
The used Baudrate can be set in “Baudrate” in the Device Communication Object (0x2001sub1).
Supported Baudrates are specified in the EDS-file.
Possible values are:
0: 1000 kbit/s
1: 800 kbit/s (not supported)
2: 500 kbit/s (default)
3: 250 kbit/s
4: 125 kbit/s
5: 100 kbit/s
6: 50 kbit/s
7: 20 kbit/s
8: 10 kbit/s
RESETS
A reset can be called by writing “Reset” in the Device Communication Object (0x2001sub4).
Possible values are:
1: Communication Reset
2: Node reset (device reset)
3: büS reset
4: Factory reset
5: restart device in bootloader mode
