0x2D02 FlowSensor
Detailed information see attachement: General Description of flow sensor.
sub name description
ac
ce
ss
type
flags accessrights
im
p
o
rt
Im
p
o
rt
d
e
vID
S
IM
-C
a
rd
R
-
u
se
r
W
-
u
se
r
R
-
a
d
v.
u
s
e
r
W
-
a
d
v.
u
se
r
R
-
in
sta
ll
e
r
W
-
ins
ta
lle
r
R
-
b
u
e
rke
rt
W
-
b
u
e
rke
rt
1 Acitve Calibration Curve
Specifies the choosen gas calibration (1..x).
The amount of the supported gas calibrations of the device
is specified by the possible max value.
RW x x x x x x x x x x
2 Sensor Type
0: SFS 7011
1: Inline Chip Digital
RO - - x - x - x x
3 Calibration Active
0: normal mode (calibration inactive)
1: calibration active
FlowSensor without temperature compensation has to
be set by testbench during calibration
RW x - x x x x x x
4 Output Filter
filter for the actual flow
since EDS 1.4 cutoff frequency fg in Hz as FLOAT32
(default 5Hz)
RW x x x - x x x x x x
5
Medium Temp Limit
Low A device warning will be generated if medium temperature
falls below this value as float32 in degree celsius
RO - - - - x - x x
6
Medium Temp Limit
High A device warning will be generated if medium temperature
passes this value as float32 in degree celsius
RO - - - - x - x x
