33
Installation
7.3.2. Anschlüsse Feldbustechnik
Pin Profibus DP CanOpen / DeviceNet Profinet,
Ethernet/
IP,
Modbus
TCP
IP20 IP54 IP20 IP54
1 n. c. +5 V n. c. Drain TX+
2 n. c. RxD/TxD-N/A-
Leitung CAN LOW n. c. TX–
3 RxD/TxD-P/B-
Leitung
DGND GND GND RX+
4 CNTR-P
(RTS)
RxD/TxD-P/B-
Leitung n. c. CAN HIGH n. c.
5 DGND Schirm n. c. CAN LOW n. c.
6 +5 V n. c. RX–
7 n. c. CAN HIGH n. c.
8 RxD/TxD-N/A-
Leitung
n. c. n. c.
9 n. c. n. c.
D-SUB 9 5-polig M12 D-SUB 9 5-polig RJ45
female female
(Reverse-Key) male Micro 12 female
male
female
D-SUB 9
IP20
Pin 1 Pin 4
1 2 3 4 5 6 7 8
Buchse RJ45
7.3.3. Anschlüsse Spannungsversorgung
Pin Alle Ausführungen
IP20 IP54
1 GND Outputs 24 V DC Outputs
2 24 V DC Outputs 24 V DC Logik
3 GND Logik GND Logik
4 24 V DC Logik GND Outputs
Typ 8640
deutsch
