Assembly
6.2.3. Dimensions of the flange images for AirLINE Quick
Inside wall control cabinet
Space requirements reinforcing frame outside
G
N4
N3
N2
N1
M
only at O= 6 and O = 10
Ø 5.3 ± 0.2
59
±
0.3
73
±
0.3
(96)
R 6.5
t>=1.5
>=8
Fig. 7: Dimensions of the flange images for AirLINE Quick – for dimensions see “Tab. 1”, page 12
