7.3.6. Address on the internal RIO bus:
DIP switches 1 to 3
Each peripheral terminal has a unique address. This address is set
on the valve terminal via DIP switches 1 to 3.
DIP 1 DIP 2 DIP 3 Address Peripheral
terminal
OFF OFF OFF 0 0
ON OFF OFF 1 1
OFF ON OFF 2 2
ON ON OFF 3 3
OFF OFF ON 4 4
ON OFF ON 5 5
OFF ON ON 6 6
ON ON ON 7 7
7.3.7. Mode inputs: DIP switches 4 and 5
NOTE!
The input modes allow the entries (feedback indicator) to be
assigned in different ways in the process image of the inputs
(PAE).
DIP 4 DIP 5
No entries available OFF OFF
Normal mode ON OFF
Mode: shifted inputs OFF ON
Mode: halved inputs ON ON
CAUTION!
If there are no inputs available, both switches must be set to OFF.
