Brooks ® Model 5850E
2-4
Installation and Operation Manual
X-TMF-5850E-MFC-eng
Part Number: 541B102AAG
September, 2009
Section 2 Installation
Figure 2-2 Model 5850E Card Edge Connector Comparison Guide
Terminal
Designation
Unit Tylan Tylan Brooks Card Brooks Tylan Tylan Unit
UFC-1000 FC-280 FC-260 5850E Edge 5850E FC-260 FC-280 UFC-1000
Chassis Chassis Chassis Chassis Command Command Command Command
Ground Ground Ground Ground 1 A Input Input Input Input
0-5 Volt 0-5 Volt 0-5 Volt Signal &
Supply Signal Signal Signal 2 B Command Command Command Command
Common Common Common Common Common Common Common Common
0-5 Volt 0-5 Volt 0-5 Volt 0-5 Volt Supply Supply
Signal Signal Signal Signal 3 C Voltage Voltage Return Common
Output Output Output Output Common Common
+ 15 Vdc + 15 Vdc + 15 Vdc + 15 Vdc 4 D Valve Test Valve Test Valve Test
Supply Supply Supply Supply Point/Purge Point Not Used Point/Purge
Remote Valve
Not Used Not Used Not Used Transducer 5 E Not Used Not Used Test Not Used
Input*** Point
Zener Zener - 15 Vdc - 15 Vdc - 15 Vdc - 15 Vdc
Not Used Test Test Not Used 6 F Supply Supply Supply Supply
Slot Slot Slot Slot 7 H* Slot Slot Slot Slot (G)
Not Used Not Used Not Used Not Used 8 J* Not Used Not Used Not Used Not Used (H)
Not Used Not Used Not Used Valve Override 9 K* Not Used Not Used Valve Not Used (I)
Open/Close
+ 5V Ref. *** or
Common Not Used Not Used Valve Return 10 L* Valve Not Used Not Used Valve Off (J)
or Not Used Off Off
* Unit designates Pins H, J, K, & L as G, H, I, & J
** Jumper Selectable
*** Factory Activated Option
