Hide hide--a a--goose goose, Installation instructions, ram 3500 – Draw-Tite 9466 HIDE-A-GOOSE - RAM User Manual
Page 3
Figure’s 2.
Looking down inside bed of truck from above
Hide
Hide--A
A--Goose
Goose
Installation Instructions, Ram 3500
Part Numbers:
9466
30,000 LB
(13620 Kg) Max Gross Trailer Weight (GTW)
7500 LB
(3405 Kg) Max Tongue Weight (TW)
Do Not Exceed
Lower of Towing Vehicle Manufacturer’s Rating or:
This hitch meets all requirements of:
SAE J2638
Society of Automotive Engineers Standard for
Fifth Wheel and Gooseneck attachment performance
With hitch bolted in place and holes for u-bolts
drilled up through bed
TM
z
z
z
z 2013 Cequent Performance Products
Sheet 3 of 12
9466N
4-8-13
Rev. A
With ball removed and magnet cover in place
With u-bolts attached through holes drilled from below,
and ball in place properly locked
