5.8 Transitions
5.8.4 Step back
The STEP BACK button in the Orchestra² Transition section, allows you
to literally go back one step. If you have made a mistake in your Main
output setup, and wish to revert to the previous state, press the STEP
BACK button, then press the TAKE button, the Orchestra² will revert
to the previous step.
NOTE:
• You can use the STEP BACK button as a way to toggle between two presets. Simply press the STEP BACK
button and then the TAKE button as many times as you like, thus switching back and forth between two
presets.
• Press and hold the STEP BACK button to activate the Preset Toggle function.
5.8.5 Take Cut
The TAKE CUT button has exactly the same function as the TAKE button, other than it overrides all transitions
between presets with a cut effect. For example, a PIP with a slide in from left effect, will simply appear
onscreen in its final position, without executing the effect.
5.8.6 Init-T-bar
The Init-T-Bar button will help the unit to reduce theT-Bar delay warning the device that the user wants to
take smoothly.
First, press the Init-T-Bar button then use theT-Bar in order to have a smooth transition.
5.8.7 Quick Frame
The QUICK FRAME button of the Orchestra², allows the instant display of a stored emergency frame above
all layers.
Visit the Controls page (Screen Setup) for configuring the Quick Frame for the current screen.
NOTE: This function requires Eikos², Saphyr, SmartMatriX², Pulse², QuickMatriX and QuickVu.
3 functions associated with TAKE
and T-BAR:
- STEP BACK - short press activates
the Step Back function
- STEP BACK - long press to enable/
disable the PRESET TOGGLE
function.
- INIT T-BAR
- TAKE CUT
