31
PIPs on your Screen can be resized, positioned; you can add borders, transparency and create other effects.
To position a PIP:
1. Select the PIP you wish to move.
2. In the Layout section, press the POS button, and move the PIP with the help of the joystick (see also Using
The Joystick).
3. When you have reached the desired position, press the TAKE button to view the result on the Main output.
To resize a PIP:
1. Select the PIP you wish to resize.
2. In the Layout section, press the SIZE button, and resize the PIP with the help of the joystick (see also Using
The Joystick).
3. When you have resized your PIP, press the TAKE button to view the result on the Main output.
To zoom into and out of a PIP:
1. Select the PIP you wish to zoom in or out of.
2. In the Layout section, press the ZOOM button, and adjust the zoom in the PIP with the help of the joystick
(see also Using The Joystick).
3. When you have set the PIP zoom, press the TAKE button to view the result on the Main output.
To add a border to a PIP:
1. Select the PIP you wish to add a border to.
2. Select the element page on your touch screen, press the BORDER button in the Preset Edition Section to
access border settings displayed on the tactile screen of the Orchestra² (see also Element Settings).
3. Set border attributes.
4. Press the TAKE button to view the result on your Main output.
5.5.4 PIP depth
The PIP depth allows users to move PIPs up or down through the successive layer hierarchy. In other words,
you can change the order of a PIP from beneath another PIP to above it, or vice-versa.
1. Select the PIP you want to move up or down.
2. In the preset Preset Edition section, press the LOWER button to move the PIP down, press the RAISE button
to move the PIP up.
5.5.5 Clearing a PIP
To clear a PIP from your Screen, proceed as follows:
1. Select the PIP you wish to clear.
2. Press the CLEAR button once. In the Orchestra² Settings section, the touch screen will ask to confirm in
the form of a message on a yellow banner at the bottom of the screen. Press the CLEAR button again to
confirm. The PIP will disappear from the Preview output.
3. Press the TAKE button to view the result on your Main output.
NOTE: To clear all PIPs from your Screen, press the CLEAR PIPs button rather than the CLEAR button.
5.5 Working with PIPs
5.5.3 Manipulating a PIP
