2.4 Hardware specifications
2.4 Hardware specifications
• Cooling air flow from right side to left side
• Maximum ambient operating temperature: < 40 °C ( < 104°F)
• Operating temperature: 0 to 40 °C / +32 ° to +104 °F -40
• Storage temperature: to 70 °C to -40 °C / -40°F to +158 °F
• Operating humidity: 10 to 80% (non condensing)
• Input voltage range: 100-240 VAC, 50/60 Hz
• Typical consumption: 50 W
CE Compliancy, test following:
- EN 55022: 2006 / A1: 2007
- EN 55024: 1998 / A1: 2001 / A2: 2003
- EN 61000-3-2: 2006
- EN 61000-3-3: 1995 / A1: 2001 / A2: 2005
Safety: test following:
- IEC 60950-1:2005
- UL 60950-1: 2007
- CAN/CSA-C22.2 NO. 60950-1
• Power supply: IEC/EN/UL/CSA 60950-1, internal, autoswitchable
• Mechanical (in carton): Vibration: IEC60068-2-64
• Free fal: IEC60068-2-32, RoHS, WEEE
Dimensions:
 W 450 x D 440 x H 180 mm
 17.71”W x 17.32”D x 7.1”H
Weight:
 9 kg / 19.8 lb
