19
4.1 Operational configuration
4. STARTING WITH THE ORCHESTRA²
4.1 Operational configuration
When the Orchestra² starts up, the User page will be displayed over the Home page. Here, you can create a
new user, or use an existing one. The first time you use the Orchestra², you will have to create a new user.
1. Press the NEW USER button on the touch screen.
2. The Orchestra² will display the User Edit screen, which allows
you to name the new user as required. When you have
entered a user name, press the OK button to validate your
choice. Press OK again if you do not wish to create a password
for the new user. Otherwise, enter a user password which will
be asked every time you wish to log in as that user.
3. On the User page, choose the user you have just created, and
press the OK button again. The Orchestra² will now display its
home page.
The Orchestra² System Configuration page allows you to parameter the IP address of the Orchestra², caliber
the joystick, the keyboard brightness, set the time, or check the software version and update it via the USB
port if required.
1. Press the SYSTEM button on the touch screen. The Orchestra²
will display the network configuration page of the System
menu.
2. Press the LAN SETTINGS button to enter the IP adress.
3. Rotate the corresponding knobs to change the IP address of
the Orchestra² (IP1, IP2, IP3, IP4) then press the OK button to
validate.
NOTE: The Orchestra² must be on the same network as the devices it is going to control.
4.1.1 User configuration
4.1.2 System configuration
