90° bend internal cover, Tee flat cover, 90° bend external cover – Carlon Structured Cable Management Systems Handbook - Low Res User Manual
Page 86: Tee external cover
84
Std. Ctn. Wt. (lbs.)
Part No.
Size
Qty.
ea.
* EGLIJ
2 x 2
1
0.3
† EGLIL
3 x 3
1
0.7
† EGLIN
4 x 4
1
1.1
† EGLIR
6 x 6
1
3.0
90° Bend Internal Cover
(Clip-on Cover)
Std. Ctn. Wt. (lbs.)
Part No.
Size
Qty.
ea.
* EGTFJ
2 x 2
1
0.4
* EGTFL
3 x 3
1
0.9
† EGTFN
4 x 4
1
1.4
† EGTFR
6 x 6
1
3.8
Tee Flat Cover
(Clip-on Cover)
Std. Ctn. Wt. (lbs.)
Part No.
Size
Qty.
ea.
* EGLEJ
2 x 2
1
0.3
† EGLEL
3 x 3
1
0.8
† EGLEN
4 x 4
1
1.2
† EGLER
6 x 6
1
3.3
90° Bend External Cover
(Clip-on Cover)
Std. Ctn. Wt. (lbs.)
Part No.
Size
Qty.
ea.
† EGTEJ
2 x 2
1
0.4
† EGTEL
3 x 3
1
0.9
† EGTEN
4 x 4
1
1.4
† EGTER
6 x 6
1
3.8
Tee External Cover
(Clip-on Cover)
* Molded fitting–couplings not needed
† Fabricated fitting–order couplings separately
†† No coupling is required for 6" fabricated end cap
