Introduction
Table of Contents
Section
Page
1.
Questions about Carlon
®
Structured Cable
Management Systems and Carlon
®
Resi-Gard
®
........... 2
2.
Defining the Application.................................................. 7
3.
Low Voltage Brackets .................................................... 11
4.
Fire Rated Applications.................................................. 14
5.
Varying Finished Wall Thickness.................................... 16
6.
Dual Voltage Box/Bracket.............................................. 19
7.
Electrical Box “Add-On”................................................ 20
8.
Fire Rated Dual Voltage Box ......................................... 21
9.
Resi-Gard
®
Flexible Raceway Systems......................... 22
10.
Interference and Installation Issues Affecting
Structured Cable Management Systems...................... 30
11.
Codes and Standards Affecting Installation Of
Structured Cable Management Systems ..................... 37
12.
Abandon Cable Issue..................................................... 58
13.
Carlon Structured Cable Management Systems.......... 61
14.
Appendix ....................................................................... 85
This pocket handbook is intended to be used as a guide
for the installation of the Carlon
®
Structured Cable
Management Systems to answer general questions relating
to installation procedures. For information on part numbers
or pricing, please refer to to the appropriate Carlon catalog
(2F54). Should the installer develop any unique installation
or support methods not shown in this manual, please
photograph the method with a 35mm or digital camera
and contact your local Carlon sales representative.
THIS POCKET HANDBOOK IS INTENDED AS A GUIDE FOR
GENERAL PURPOSES ONLY. CARLON ACCEPTS NO LIABILITY
FOR ANY DAMAGES OR LOSS WHICH MAY RESULT FROM
IMPROPER INSTALLATION OF CARLON STRUCTURED CABLE
MANAGEMENT SYSTEMS AND CARLON
®
RESI-GARD
™
.
