Resi-rings – Carlon Structured Cable Management Systems Handbook - Low Res User Manual
Page 14

12
ANOTHER INSTALLATION ISSUE IS WHAT
TO DO WITH THE CABLE FROM THE TIME
YOU INSTALL THE BOX TO THE TIME YOU
CONNECT THE CABLE?
Resi-Rings
The
3
/
4
" Resi-Rings
attached directly to the
box serve more than one
purpose. You can run
the cable through both
rings and let the cable
hang loose.
Or – for extra security,
run the cable through the
Resi-Rings and then wire-
tie the cable directly to
the ring.
Using this feature allows
you easy accessibility to
the cable later on and
keeps the cable safely out
of the way from other
trades.
What other uses do the
rings have? The Resi-
Rings also accommodate
Resi-Gard flexible raceway.
Resi-Gard is Carlon’s
newest flexible raceway
system for cable
protection, management,
and future-proofing
applications.
Resi-
Rings
Gross Automation (877) 268-3700 · www.carlonsales.com · [email protected]
