Version 08.00, January 2012
Rohde & Schwarz R&S ® SMU200A Vector Signal Generator 7
Modulation
Possible modulation types
RF path A
Amplitude modulation, frequency/phase modulation (optional), vector modulation, digital modulation via internal baseband section
(optional), vector modulation via baseband inputs (optional), pulse modulation, wideband amplitude modulation
RF path B
Amplitude modulation, digital modulation via internal baseband section (optional), vector modulation via baseband inputs (optional),
pulse modulation
Simultaneous modulation
In the same RF path
AM FM φM PM WB-AM I/Q DM ARB
Amplitude modulation (AM) / ● ● ● – – – –
Frequency modulation (FM) ● / – ● ● ● ● ●
Phase modulation ( φM) ● – / ● ● ● ● ●
Pulse modulation (PM) ● ● ● / ● ● ● ●
Wideband AM (WB-AM) – ● ● ● / – – –
Vector modulation (I/Q) – ● ● ● – / – –
Digital modulation (DM) – ● ● ● – – / –
ARB – ● ● ● – – – /
● = compatible, – = not compatible, switch off each other
