Sweep time and triggering
Range
Span = 0 Hz
1 μs to 6000 s
Span ≥ 10 Hz
1 ms to 4000 s
Accuracy
Span ≥ 10 Hz, swept
± 0.01% nominal
Span ≥ 10 Hz, FFT
± 40% nominal
Span = 0 Hz
± 0.01% nominal
Trigger
Free run, line, video, external 1, external 2, RF burst, periodic timer
Trigger Delay
Span = 0 Hz or FFT
–150 to +500 ms
Span ≥ 10 Hz, swept
0 to 500 ms
Resolution
0.1 μs
Time gating
Gate methods
Gated LO; gated video; gated FFT
Gate length range (except method = FFT)
100.0 ns to 5.0 s
Gate delay range
0 to 100.0 s
Gate delay jitter
33.3 ns p-p nominal
Sweep (trace) point range
All spans
1 to 40001
Resolution bandwidth (RBW)
Range (–3.01 dB bandwidth)
1 Hz to 3 MHz (10 % steps), 4, 5, 6, 8 MHz
Bandwidth accuracy (power)
1 Hz to 750 kHz
± 1.0 % (± 0.044 dB)
820 kHz to 1.2 MHz (< 3.6 GHz CF)
± 2.0 % (± 0.088 dB)
1.3 to 2 MHz (< 3.6 GHz CF)
± 0.07 dB nominal
2.2 to 3 MHz (< 3.6 GHz CF)
± 0.15 dB nominal
4 to 8 MHz (< 3.6 GHz CF)
± 0.25 dB nominal
Bandwidth accuracy (–3.01 dB)
RBW range
1 Hz to 1.3 MHz
± 2 % nominal
Selectivity (–60 dB/–3 dB)
4.1:1 nominal
EMI bandwidth (CISPR compliant)
200 Hz, 9 kHz, 120 kHz, 1 MHz
(Option EMC or N6141A required)
EMI bandwidth (MIL STD 461E compliant)
10 Hz, 100 Hz, 1 kHz, 10 kHz,
100 kHz, 1 MHz
(Option EMC or N6141A required)
Analysis bandwidth
1
Maximum bandwidth
Option B40
40 MHz
Option B25 (standard)
25 MHz
Standard
10 MHz
Video bandwidth (VBW)
Range
1 Hz to 3 MHz (10 % steps), 4, 5, 6, 8 MHz, and wide open (labeled 50 MHz)
Accuracy
± 6 % nominal
Measurement speed
3
Standard nominal
Option PC4 nominal
Local measurement and display update
rate
11 ms (90/s)
4 ms (250/s)
Remote measurement and LAN transfer
rate
6 ms (167/s)
5 ms (200/s)
Marker peak search
5 ms
1.5 ms
Center frequency tune and transfer (RF)
22 ms
20 ms
Center frequency tune and transfer (μW)
49 ms
47 ms
Measurement/mode switching
75 ms
39 ms
1. Analysis bandwidth is the instantaneous bandwidth available around a center frequency over which the input signal can be digitized for further
analysis or processing in the time, frequency, or modulation domain.
2. Sweep points = 101.
