Corrected System Performance
The specifications in this section apply for measurements made with the N5230A Options
140, 145, 146, 240, 245, and 246 analyzers with the following conditions:
• 10 Hz IF bandwidth
• No averaging applied to data
• Isolation calibration with an averaging factor of 8
Table 1. System dynamic range at test port 1
Standard configuration and standard power range (Options 140, 240)
Description
Specification (dB) Typical (dB)
at test port at test port
300 kHz to 10 MHz 2 111
10 MHz to 4 GHz 2 120 128
4 to 6 GHz 118 129
6 to 10.5 GHz 115 127
10.5 to 13.5 GHz 107 119
13.5 to 15 GHz 107 119
15 to 20 GHz 103 116
Configurable test set and extended power range (Options 145, 245)
Configurable test set, extended power range, and internal second source
(Options 146, 246)
Description
Specification (dB) Typical (dB)
at test port at test port
300 kHz to 10 MHz 2 111
10 MHz to 4 GHz 2 120 128
4 to 6 GHz 118 128
6 to 10.5 GHz 113 125
10.5 to 13.5 GHz 105 117
13.5 to 15 GHz 105 11
15 to 20 GHz 98 115
1. The system dynamic range is calculated as the difference between the noise floor and the specified
source maximum output power. The effective dynamic range must take measurement uncertainties
and interfering signals into account.
2. May be degraded by 10 dB at particular frequencies (multiples of 5 MHz) below 500 MHz due to
spurious receiver residuals. Methods are available to regain the full dynamic range.
