11
Table 6. Test port output 1
Description
Specifications Typicals
Options Options Options Options
140, 240 145, 146, 245, 246 140, 240 145, 146, 245, 246
Frequency range
Options 140, 145, 146 300 kHz to 13.5 GHz
Options 240, 245, 246 300 kHz to 20 GHz
Nominal power
–5 dBm –8 dBm Preset power; attenuator switch
point 10 dB below nominal power
Frequency resolution
1 Hz
CW accuracy
±1 ppm
Frequency stability
±0.05 ppm. –10° to 70° C
±0.1 ppm/yr maximum
Description
Specifications Typicals
Options Options Options Options
140, 240 145, 146, 245, 246 140, 240 145, 146, 245, 246
Power level accuracy
Variation from nominal power in range 0
300 kHz to 10 MHz
±1.0 dB ±1.0 dB
10 MHz to 2 GHz ±1.0 dB ±1.0 dB
2 to 10.5 GHz ±1.5 dB ±1.5 dB
10.5 to 13.5 GHz ±2.5 dB ±2.5 dB
13.5 to 20 GHz ±2.5 dB ±2.5 dB
Max leveled power
300 kHz to 10 MHz
+8 dBm +8 dBm
10 MHz to 4 GHz +8 dBm +8 dBm +12 dBm +11 dBm
4 to 6 GHz +6 dBm +6 dBm +10 dBm +9 dBm
6 to 10.5 GHz +3 dBm +1 dBm +8 dBm +6 dBm
10.5 to 13.5 GHz 0 dBm –2 dBm +5 dBm +3 dBm
13.5 to 15 GHz 0 dBm –2 dBm +5 dBm +3 dBm
15 to 20 GHz –3 dBm –8 dBm +2 dBm –1 dBm
Power level linearity
Specified on Port 1 only. Ports 2, 3, 4 performance is Typical. Test is at the nominal power level.
300 kHz to 10 MHz
±2.0 dB ±2.0 dB
10 MHz to 1 GHz ±2.0 dB ±2.0 dB
1 to 13.5 GHz ±1.5 dB ±1.5 dB
13.5 to 20 GHz ±1.5 dB ±1.5 dB
Power sweep range (ALC)
ALC range starts at maximum-leveled power and decreases by the dB amount specified here.
300 kHz to 10 MHz
35 dB 35 dB
10 MHz to 4 GHz 33 dB 33 dB
4 to 6 GHz 31 dB 31 dB
6 to 10.5 GHz 28 dB 26 dB
10.5 to 13.5 GHz 25 dB 23 dB
13.5 to 15 GHz 25 dB 23 dB
15 to 20 GHz 22 dB 17 dB
Power resolution
0.01 dB 0.01 dB
